A RedCap Module That Drops Into the Older Footprint

Fibocom has launched the RU311 series of 5G RedCap modules, built on the UNISOC V527 platform and announced on 2 September. Throughput is 226 Mbps downlink and 120 Mbps uplink on RedCap, with LTE Cat.4 fallback at 150 Mbps down and 50 Mbps up. The LGA package measures 32 by 29 by 2.4 millimetres, with M.2 and Mini PCIe variants also offered. Supported protocols include TCP and UDP, HTTP and HTTPS, SSL and MQTT; interfaces cover USB, UART, RGMII, SDIO, I2C, SPI and GPIO. Target applications are industrial gateways, routers, surveillance systems, automotive and portable hotspots. The detail Fibocom leads with is pin compatibility: the LGA layout matches its existing FG132 RedCap module and its NL668 and L716 Cat.4 modules.

That pin compatibility is the commercially significant part, and it explains what RedCap is actually for. RedCap — reduced capability — exists because full 5G modules are too expensive, too power-hungry and too physically large for the enormous middle of the IoT market that currently runs on LTE Cat.4 and Cat.1. Its purpose is to be the migration path when LTE networks are eventually refarmed, and a migration path that requires a board respin is not a migration path; it is a new product. A module that drops into the existing footprint turns a forced technology change into a bill-of-materials substitution.

The numbers are worth reading as a category description rather than a spec sheet. 226 Mbps downlink is well below full 5G and far above what almost any industrial gateway, meter concentrator or telemetry device needs; the useful properties are lower module cost, lower power and access to 5G networks, not throughput. For anything that was specified around Cat.4, RedCap changes nothing about what the application can do and changes a great deal about how long the design remains supportable.

For product teams the practical question is timing, and it is a regional one. LTE sunset schedules vary widely by country and operator, and a device shipping today with a five to ten year field life may outlive the network it was designed for in some markets and not others. The sensible hedge is exactly what this pinout enables: design the board once, fit the Cat.4 module while it is cheaper, and keep the RedCap part qualified as a drop-in for the production run that needs it. That is a decision worth making explicitly at design time, because the cost of it is close to zero then and close to a redesign later.
